SGP30 GY-SGP30 CO2 I2C SPI Luftqualität- Air- Gas- Sensor

10,98

SGP30 GY-SGP30 CO2 I2C SPI Luftqualität- Air- Gas- Sensor

Lieferzeit: sofort

2 vorrätig

EAN Code N/A Artikelnummer: 284561462811-SGP30 Kategorie: Schlagwörter: , , , , , , , , , , ,

Beschreibung

SGP30 GY-SGP30 MOX MOS VOC TVOC CO2 I2C SPI Luftqualität- Air- Gas- Sensor Module IAQ Index

SGP30 VOC TVOC CO2 eCO2 Sensor Module © androegg

CO2 VOC TVOC IAQ Index Luftqualität Sensor wie folgt verfügbar:

  • SGP30 eCO2 VOC TVOC I2C Sensor Modul 2V-5V

Die Luftqualitäts – Sensoren erlauben die Bestimmung von

  • VOC (Volatile Organic Compound) flüchtigen organischen Verbindungen in der Luft
  • TVOC (Total Volatile Organic Compound)
  • CO2 / eCO2 (equivalent CO2) äquivalent berechnete Kohlendioxid Konzentration
  • mit einer Messtoleranz von 15% (Sensor zu Sensor)



Die Grundlage zur Messung erfolgt dabei basierend auf typischen MOX Sensoren, zusammenfasst eine beheizte MetallOxid beschichtete Fläche absorbiert Sauerstoff (niedriger Widerstand) mit einem Anstieg erhöhter Bindung an VOC steigt der Widerstand.



Der SGP-30 ermittelt eCO2 Konzentrationen im Bereich von 400 bis 60.000 ppm und TVOC Konzentrationen im Bereich von 0 bis 60.000 ppm. Die eCO2 Bestimmung erfolgt dabei auf der Grundlage der H2 Konzentration. Diesbezüglich kann der SGP30 zusätzlich in Kombination mit einem Luftfeuchte Sensor Modul wie beispielsweise unserem

HTU21-D

HDC-1080

betrieben werden.

CO2 VOC TVOC IAQ Index Air Quality Sensor Module:

  • SGP30 eCO2 VOC TVOC I2C Modul 2V-5V



The Air- Quality Sensor Modules measures

  • VOC Volatile Organic Compound
  • TVOC Total Volatile Organic Compound
  • CO2 / eCO2 equivalent CO2 calculated CO2 Concentration
  • 15% Sensor-to-sensor deviation

The SGP30 detect eCO2 Concentration from 0 to 60,000 ppb and TVOC from 0 to 60,000 ppb. The eCO2 Concentration is based / calculated on H2 concentration. Therefore the SGP30 Sensor Modul can be oprated in Combination with a Humidity Sensor such as

HTU21-D

HDC-1080





SGP30 Air Quality Sensor Features:

  • Supply Voltage
    • 1.8-5V
  • Supply Current
    • 2 µA sleep mode
    • 48.8 mA measurement mode
  • I2C Interface
  • Sampling Rate 1Hz
  • TVOC Signal 0 ppb – 60000ppb
  • CO2e Signal 400 ppb – 60000ppb
