Flachbandkabel / Ribbon Cable 14 polig / core FC14P IDC Buchse / Socket JTAG AVR 2.54

IDC FC14P 14 core cable 300mm © androegg

FC14P cable drawing © androegg

ISP Kabel zum Verbinden von seriellen Verbindungen wie beispielsweise

• ISP In System Programming
• TPI Tiny Programming Interface
• PDI XMEGA
• USB TTL Converter
• openOCD
• JTAG Debugging Schnittstelle
• ST Link
• USBASP
• RS232
• serial Interfaces
• …

14-adriges IDC FC16P Kabel 300mm

Bitte die jeweilige Belegung des AVR in System Programmer beachten.

14 core ISP Cable for connecting

• ISP In System Programming
• TPI Tiny Programming Interface
• PDI XMEGA
• USB TTL Converter
• openOCD
• JTAG Debugging Interface
• ST Link
• USBASP
• RS232
• serial Interfaces
• …

14 core IDC FC16P Cable 300mm

Please note respective Pinout of designated AVR In System Programmer.

IDC FC14P Cable Features:

• length 300mm
• 14 core
• FC14P Connector female / female 2.54 mm pitch
• 28AWG cable 1.27 mm mitch
• up to 105°C
• Withstand Voltage: 300V
